IMAGE Frac™ pressure-based fracture geometry

Simple | Accurate | Affordable

Fracture intelligence on every well

Reveal Energy Services is the go-to source to validate your completion design on every well with minimum operational risk and cost. IMAGE Frac™ technology is a new approach to mapping hydraulic fractures, enabling operators to work with factory mode consistency that increases reservoir contact by confirming whether a stimulation treatment is producing the planned fracture dimensions. Our technology generates fracture maps with half-length, height, and asymmetry to support your well objectives.
